Mimaki CJV150-160 Printer and Cutter
The ability to pre-cut before printing prevents common problems such as film separation and other issues related to post-cutting on thin materials.
Eco Solvent or Dye Sublimation
The CJV150 Series can be configured for either eco solvent printing for sign and graphics applications or for dye-sublimation printing for textile and apparel transfer sublimation applications.
Expanded Eco Solvent Ink Set with Silver
The SS21 eco solvent ink set includes ten colors including Silver, which can be used to create metallic color effects for labels, decals and package prototyping jobs.
Uninterrupted Ink Supply System (UISS)
When printing in CMYK, CJV150 Series printers can be configured with two ink cartridges per color. Utilizing the UISS (Uninterrupted Ink Supply System) when one cartridge is emptied, the printer automatically switches to the full cartridge to deliver continuous imaging.
Precision Ink Drop Placement
Mimaki designed an optimum waveform enabling the print head to jet each ink color at the appropriate jetting angle without losing precise ink droplet circularity.
Variable drop printing combined with MAPS3 (Mimaki Advanced Pass System 3) technology ensures precise and accurate print quality throughout the printing process, greatly reducing the appearance of banding and resulting in a smoother image.
Uniform Media Drying
A Mimaki-patented, three-way intelligent heating system results in uniform ink drying across the width of the printer, assuring even image quality.
- Pre-heater: Heats media to the optimum temperature before printing.
- Print heater: Dries ink after it lands on media before it bleeds, improving color development.
- Post-heater: Enhances ink drying and achieves stable take-up.
- Top blower: Air blower supports drying of ink.
What you can do with the Mimaki CJV150 Series
With eco solvent inks:
- Vehicle graphics
- Point-of-purchase displays
- Exhibition graphics
- Window clings
- and more…
With dye sublimation inks:
- Fashion & Sportswear
- Exhibition soft signage
- T-shirt transfers
- and more…
With on-board cutting:
- Vehicle markings
- Apparel transfers
- and more…
Technical overview of the Mimaki CJV150 Series
|Print System||On-demand piezo, one print head per color 8 channels for a variety of|
|Maximum print width||CJV150-75: 31.4 inches (800 mm)|
CJV150-107: 42.9 inches (1090 mm)
CJV150-130: 53.5 inches (1361 mm)
CJV150-160: 63.3 inches (1610 mm)
|Print resolution||360, 540, 720, 1,080, 1,440 dpi|
|Ink Type||Mimaki SS21 Eco-Solvent: C, M, Y, K, Lc, Lm, Lk, Or, W, Si|
Mimaki ES3 Eco-Solvent: C, M, Y, K, Lc, Lm, W
Mimaki Sb54 Dye Sublimation: Bl, M, Y, K, Lbl, Lm
|Ink Capacity||440ml cartridges available for most colors|
220ml cartridges only for Silver and White ink
Optional: 2-liter bulk ink system standard for most colors
|Maximum media width||CJV150-75: 31.8 inches (810 mm)|
CJV150-107: 43.1 inches (1100 mm)
CJV150-130: 53.9 inches (1371 mm)
CJV150-160: 63.7 inches (1620 mm)
|Max roll weight||88 lbs. (40 kg)|
|Media thickness||1.0 mm|
|Operational environment||Temp: 59?? – 86?? F (15?? – 30?? C)|
35-65% RH (non-condensing)
|Power supply||Single-phase AC 100-120V (AC 220-240V) x2|
|Dimensions (W × D × H)||CJV150-75: 77 x 28 x 55 inches (195 x 71 x 140 cm)|
CJV150-107: 89 x 28 x 55 inches (226 x 71 x 140 cm)
CJV150-130: 99 x 28 x 55 inches (251 x 71 x 140 cm)
CJV150-160: 109 x 28 x 55 inches (277 x 71 x 140 cm)
|Weight||CJV150-75: 278 lbs. (126 kg)|
CJV150-107: 313 lbs. (142 kg)
CJV150-130: 346 lbs. (157 kg)
CJV150-160: 370 lbs. (168 kg)
Ink for the Mimaki CJV150 Series
|Eco Solvent ink (SS21)||Cyan||Magenta||Yellow||Black||Light Cyan||Light Magenta||Light Black||Orange||White||Silver|
|2L MBIS Pack*||SPC-0588C||SPC-0588M||SPC-0588Y||SPC-0588K||SPC-0588LC||SPC-0588LM||SPC-0588LK||SPC-0588OR|
|Eco Solvent ink (ES3)||Cyan||Magenta||Yellow||Black||Light Cyan||Light Magenta||Light Black||Orange||White||Silver|
|Dye Sublimation ink (Sb54)||Blue||Magenta||Yellow||Black||Light Blue||Light Magenta||Light Black||Orange||White||Silver|
|2L MBIS Pack*||SB54-BLT-2L||SB54-MT-2L||SB54-YT-2L||SB54-KT-2L||SB54-LBT-2L||SB54-LMT-2L|
*Use of the 2L Bulk Ink Packs may require purchase of a MBIS unit.
