Allwin Board Commonly Used by AW Print head

Specifications:

• Board Type: Allwin V1.5 / V1.6 / V1.7 (AW-compatible versions)

• Print Head Compatibility: AW print heads (commonly used in Chinese solvent printers)

• Ink Type Support: Solvent / Eco-solvent

• Print Resolution: Up to 1440 dpi (dependent on system and RIP software)

• Color Support: CMYK / 6-Color / 8-Color options (based on configuration)

• Interface: USB 2.0 / Ethernet

• RIP Software Support: Maintop / Photoprint / Wasatch

• Power Supply: 24V / 36V (external power modules used)

• Panel Key Support: Compatible with standard Allwin Panel Key for manual control

• Print Head Voltage & Timing Control: Adjustable via firmware or software

Highlights:

• Designed specifically for printers using AW solvent print heads

• Offers stable communication between mainboard and printhead for smooth ink firing

• Supports single or multi-head configurations

• Compatible with widely available, cost-effective AW printheads

• User-friendly interface and software support

• Ideal for OEM manufacturers and printer assemblies

• Reliable performance in both indoor and outdoor printing environments

Applications & Uses:

• Entry- and mid-level solvent/eco-solvent printers using AW print heads

• Outdoor signage production: flex banners, billboards, and vinyl boards

• Indoor media: photo paper, posters, backlit film, stickers

• Custom-built or OEM printers built around Allwin control boards

• Cost-conscious print setups requiring durable electronics and reliable output
