Allwin Fuse Protector

Specifications:

• Product Type: Electrical Fuse Protection Module

• Compatibility: Allwin Mainboards (V1.5 / V1.6 / V1.7) and similar printer control systems

• Fuse Type: Replaceable glass or blade fuses (based on version)

• Supported Voltage: 12V / 24V / 36V DC (depending on circuit)

• Max Load: Up to 10A per channel

• Inputs/Outputs:

  • Multiple fuse lines for print head, board, and motor protection

  • Terminal connectors for power input/output

• Indicator: LED fuse status indicators (on some versions)

• Mounting Type: Panel or chassis mount

• Build Material: Industrial-grade PCB with protective casing (optional)

Highlights:

• Protects printer electronics from overcurrent, short circuits, and voltage spikes

• Prevents damage to print heads, boards, and motion systems

• Easy to replace fuses — quick restoration after faults

• Optional LED indicators for quick fuse status check

• Widely used in Allwin-based and Chinese-manufactured large-format printers

• Increases printer life span and reduces maintenance downtime

• Compact design allows easy installation in most printer cabinets

Applications & Uses:

• Installed in solvent, eco-solvent, and UV printers using Allwin or similar boards

• Used to protect print heads, mainboards, carriage motors, and heaters

• Suitable for OEM printer manufacturing and repairs

• Common in printers from brands like Allwin, Human Digital, MyJet, Wit-Color, and others

• Useful in environments with unstable power supply or heavy usage cycles
