Specifications:
Maximum Lamination Width: 1,300 mm (51.2″)
Maximum Lamination Length: 2,500 mm (98.4″)
Maximum Lamination Thickness: 50 mm (1.96″)
Lamination Type: Flatbed (table style)
Roller Diameter: 130 mm (5.1″) silicon roller
Lamination Temperature: Up to 60 °C (140 °F) for warm & cold versions
Pressure/Height Adjustment: Pneumatic or automatic
Power Supply: 110 V / 220 V, 50/60 Hz
Dimensions (Approx.): 3,410 × 1,660 × 1,215 mm
Weight: ~400 kg
Highlights:
Large-format coverage for oversized boards and graphics
Flatbed design supports rigid and semi-rigid materials
Pneumatic pressure ensures even, bubble-free lamination
Optional heating for enhanced adhesion and finish quality
User-friendly controls with height adjustment and visibility features
Versatile for multiple substrates and applications
Applications and Uses:
Signage and display graphics on rigid panels
Vehicle graphics and large-format panels
Promotional displays and point-of-sale fixtures
Post-print finishing for digital and UV prints
Prototyping and sample fabrication
Interior décor panels and architectural graphics
