Mimaki CF2-0912 Flatbed Cutting Table
Non-returnable
Tags:
Mimaki CF2-0912 flatbed cutting plotters
- Cut various kinds of media with high accuracy without dies
- Produce high value-added products on demand
- Small-lot production with unprecedented high quality
Choose Quantity
$40,000.00

Product Details
Specifications
MIMAKI CF2 SERIES FLATBED CUTTER
Mimaki CF2 Series Flatbed Cutter
The Mimaki CF2 Series flat bed cutting plotter is capable of cutting various kinds of media with high accuracy without dies. Out of a total of 30 kinds of line-up, you can choose the one best suited for your needs. By cutting the printed media, you may produce high value-added products on demand required. Begin multi-type small-lot production with unprecedented high quality.
- Thick material can be outline-cut with high accuracy.
- Composite materials etc. can be half-cut.
- Media is set easily and accurately.
- Extensive line-up of cutter blades.
- Correction of starting and ending points
- Circle correction
- Available in three sizes:
- CF2-0912: 1600mm x 1760mm (63" x 69")
- CF2-1215: 1900mm x 2060mm (74.8"x 81.1")
- CF2-1218: 1900mm x 2360mm (74.8"x 92.9")
FEATURES OF MIMAKI CF2 SERIES FLATBED CUTTER:

Materials that can be processed
Possible to cut with standard accessories.
Possible to cut with the use of optional items.


T | TF | RT | TD | RC | |
---|---|---|---|---|---|
Corrugated fiberboard(E to B corrugation)* | ![]() | ![]() | |||
Corrugated fiberboard(AB corrugation)* | ![]() | ||||
Coated board for packaging* | ![]() | ![]() | |||
Vinyl chloride for clear package* | ![]() | ![]() | |||
Plastic corrugated fiberboard | ![]() | ![]() | |||
Vinyl chloride sheet for signboard | ![]() | ![]() | ![]() | ![]() | ![]() |
Soft vinyl chloride(0.5 to 10mm) | ![]() | ![]() | |||
Reflecting sheet | ![]() | ![]() | ![]() | ![]() | ![]() |
Sand-blast rubber | ![]() | ![]() | ![]() | ![]() | ![]() |
Industrial sheet rubber(3mm or less) | ![]() | ![]() | ![]() | ![]() | ![]() |
Industrial sheet rubber(0.5 to 10 mm) | ![]() | ![]() | |||
Pattern Happort | ![]() | ![]() | ![]() | ![]() | ![]() |
Non-Stick(1.0 to 5.0mm) | ![]() | ![]() | ![]() | ||
Resin belt. (5.0mm or less) | ![]() | ![]() | |||
Various foam(20mm or less) | ![]() |
- Note) As the property of the media may vary depending on the material manufacturers, the above data is just a guide. Make sure to perform your own testing.
- Note) *shows material to which drawing of the ruled line is possible.
TECHNICAL SPECIFICATIONS
Equipment Type
- Equipment TypeCutting Table
