🔧 Print Head Configuration Options
This printer supports up to six Epson i3200 print heads (not included), allowing scalable performance based on your production needs.
⚠️ Note:Print heads are sold separately. Please view the recommended products below.
🔹 Highlights
Hybrid UV printing for both flexible and rigid media.
Open bulk ink system with no chip restrictions for maximum flexibility.
1.5L ink tanks per color for extended production runs.
High-quality components ensure long-term reliability and performance.
SAI FlexiPrint RIP software included for professional color control.
Two support tables included for enhanced media handling.
Scalable print head setup allows you to start with fewer heads and expand up to six.
📋 Technical Specifications
Feature | Description |
|---|
Model | Allwin FA 72 Hybrid UV |
Print Technology | Hybrid UV (Flexible & Rigid Media) |
Print Heads | Supports up to 6 Epson i3200 (not included) |
Print Resolution | Up to 3200 dpi |
Print Width | Up to 72 inches (6 ft / 1.8m) |
Ink Colors | CMYK + Optional White & Varnish |
Ink System | Open bulk system (chip-free), 1.5L per color |
Curing System | LED-cooled UV curing system |
Media Thickness | Up to 0.98 in (25mm) |
Media Types | Vinyl, Paper, Canvas, Banner Mesh, Fabric, Backlit Film, Acrylic, PVC, Foam Board, KT Board, MDF, Glass, Cardboard, Wood, Leather |
Tables Included | Two additional support tables |
Software Included | SAI FlexiPrint RIP |
Scalability | Ready to start with fewer heads and scale up to 6 |
Component Quality | High-quality components throughout |
Power Requirements | 220V Single-phase, 32A / 10A + N + GND |
Compressor Requirement | ≥6kg/cm² (≥87 PSI), ≥200 L/min |
Machine Dimensions | 111 x 52 x 56 in (705 lb) |
Shipping Dimensions | 130 x 51 x 59 in (1102 lb) |
