Allwin Fuse 20A

Specifications:

• Type: Blade Fuse / Glass Fuse (based on model)

• Current Rating: 20 Amperes (20A)

• Voltage Rating: DC 12V / 24V / 36V (depending on system)

• Fuse Size:

  • Blade: Standard automotive size (ATC/ATO)

  • Glass: 5x20mm or 6x30mm (as per board design)

• Compatibility: Allwin boards (V1.5 / V1.6 / V1.7) and fuse protectors

• Response Type: Fast-blow or medium-blow (depending on system requirements)

• Material: Zinc alloy or copper conductor with plastic or glass housing

• Mounting: Fuse slot or fuse holder

Highlights:

• Rated for 20A protection, ideal for print head heaters, motors, and board power circuits

• Prevents electrical damage from overcurrent and short circuits

• Compatible with Allwin mainboards and third-party fuse protectors

• Easy to install and replace — standard size for quick maintenance

• Durable and heat-resistant housing for stable long-term use

• Available in single units or packs for service and stockroom use

Applications & Uses:

• Print Head Power Protection: Ensures safe operation of solvent and UV print heads

• Mainboard Circuit Safety: Protects the control board from current spikes

• Carriage & Motor Circuits: Commonly used for motor drive and heater lines

• Fuse Protector Modules: Works with Allwin fuse protector boards for system-wide protection

• Printer Brands: Compatible with Allwin, Human Digital, MyJet, Wit-Color, and other similar systems

• Spare Parts & Maintenance Kits: Ideal for technicians and service providers
