Specifications

• Name: Left Under Cover Bracket (BKT)

• Function: Secures/aligns the left under cover; helps protect internal wiring and assemblies

• Construction: Stamped metal bracket with mounting holes (finish may vary by batch)

• Includes: Bracket only (reuse OEM screws/hardware unless otherwise noted)

• Position: Left underside cover mount (exact location varies by model)

• Compatibility: Appears in parts lists for CJV300/150 families, UCJV300-150, and certain TS300P / Tx300P variants—always confirm by serial range and exploded view before ordering.

Highlights

• OEM Fitment: Matches factory geometry and hole pattern for straightforward installation.

• Restore Cover Alignment: Fixes sag/misalignment that can cause rubbing or vibration.

• Protects Internals: Keeps the under cover correctly seated to shield cables and boards.

• Service Friendly: Drop-in replacement; no modifications required on supported models.

• Reliable: Steel construction designed for daily production environments.

Use & Details

• When to Replace: Cracked/bent bracket, missing fasteners, cover won’t sit flush, rattling from the left underside, or repeated cover removal during maintenance.

• Installation Notes:

  • Power off printer and allow heaters to cool.

  • Support the under cover; remove fasteners; swap bracket; reinstall using correct torque.

  • Reuse OEM screws or replace with identical spec; do not overtighten to avoid damaging plastic covers.

  • After fitment, verify clearances and that the cover doesn’t contact moving parts.

• Checklist Before Purchase: Printer model → serial-range parts list → bracket code M604637 → hardware reuse/need.

Note: Mimaki uses similar “Left under cover BKT” parts with different codes across families; confirm your exact model/diagram to avoid mismatches.
