Mimaki Cable Pen Fpc Assy for CG-130FX

Specifications

• Product Name: Pen FPC Assembly

• Manufacturer: Mimaki

• Cable Type: Flexible Printed Circuit (FPC)

• Length: Approximately 2,160 mm

• Width: Approximately 14 mm

• Pin Count: 10 pins

• Compatible Models: CG-130FX, CG-130FXII, CG-75FX, CG-75FXII

Highlights

• OEM-quality component ensures perfect compatibility with Mimaki cutters

• Delivers stable data transmission between control board and pen carriage

• Durable, flexible design made for repeated motion during operation

• Helps resolve signal errors and mechanical faults in the cutter system

• Easy to install during maintenance or part replacement

Applications and Uses

• Used in the pen carriage system of Mimaki CG-FX series cutting plotters

• Essential for transmitting signals that control the pen or cutter head

• Replaced when cable damage causes plotting issues or pen malfunction

• Common maintenance part to ensure reliable machine operation

• Ideal for print shops, service techs, or operators maintaining cutting precision
