Specifications
- Type: Regenerative Resistance PCB Assembly
- Function: Energy dissipation and motor braking support
- Material: Industrial-grade PCB with reinforced components
- Compatibility:
- Mimaki CJV30 Series (60, 100, 130, 160)
- Mimaki JV33 Series (130, 160, 260)
- Mimaki TPC-1000, TS3-1600
- UJF, UCJV, TX, TS, UJV Series (depending on model variant)
- Installation: Direct-fit OEM part
Highlights
- Absorbs and dissipates excess electrical energy
- Protects printer control boards from voltage spikes
- Enhances braking efficiency and motion control
- Supports long-term reliability in high-speed printing
- Manufactured to Mimaki’s strict quality standards
Uses
- Replacement for damaged or degraded resistance boards
- Essential for maintaining stable motor control
- Ideal for high-volume or precision printing environments
- Suitable for technicians and service professionals
Details
This PCB assembly plays a critical role in the internal power regulation of Mimaki printers. By managing regenerative energy from motor deceleration, it helps prevent electrical stress on the system, ensuring smooth operation and extending the life of your equipment. Whether you're upgrading or replacing a worn component, this board is a key part of maintaining professional-grade performance.
