Mimaki CFL-605RT Cutting Table

Mimaki CFL-605RT Go Beyond

• Three types of cutting a variety of materials
  • Reciprocating for substrates up to 10 mm thick
  • Tangential for media up to 2 mm thick
  • Eccentric for media up to 1 mm thick
  • Creasing roller for precise folding
• Cut and crease without changing tools
• Vacuum system for securely holding materials in place
• 20” x 24” (610 x 510 mm) cutting area
• Cut media up to 0.39” (10 mm) thick
• Quiet, compact design suitable for office or studio
• Can be part of a total solution for on-demand goods and package production

Highlights of the Mimaki CFL-605RT

Rapidly bring ideas into shape

The use of digital on-demand UV inkjet printing has increased the requirement for creating original customized goods in response to an increase in high-mix / low-volume demands in the market. As part of an overall workflow, the CFL-605RT cutting plotter provides a rapid-response solution for production of items such as short-run or custom original goods, samples and package prototyping.

Key features:

• Reciprocating cutting: for substrates such as foam cushioning materials, sponge or cardboard.
• Tangential cutting: for media such as synthetic leather, coated cardboard, reflective vinyl, rubber and fluted cardboard.
• Eccentric cutting: for media such as coated packaging materials, thin polycarbonate sheets, paper and film.
• Creasing roller: for drawing a ruled line that results in precise folding. The creasing roller can be mounted alongside cutting blade for cutting and creasing without changing tools.
• Vacuum system: for securely holding materials in place. Lightweight, thin or porous materials can be further secured by an overlaid adsorption sheet that enhances vacuum by reducing airflow through the material

Total solution for package design actualization

The combination of a CFL-605RT cutting plotter, a UJF-6042 UV-LED tabletop flatbed printer and packaging design software such as ArtiosCAD* Designer Solution provides the ability to easily and economically produce package prototypes that accurately reflect the designer’s intent. With this system, designers and brand managers can achieve packaging design actualization in shorter timeframes.

Quiet, compact operation

With a compact footprint of 52 inches by 41 inches, the CFL-605RT cutting plotter can fit unobtrusively into a design office or studio environment. Integrated casters means it can be moved where needed, and user-adjustable feet ensure stability once placed. A double-insulated vacuum unit operates quietly, on par with standard office equipment.

_{*CFL-605RT cutter and UJF-6042 printer are sold separately through Mimaki authorized representatives; ArtiosCAD software is a product of Esko-Graphics available through Esko channels.}

What you can do with the Mimaki CFL-605RT

• Package prototypes
• Short-run packaging
• Custom original goods
• Samples
• and more…

Specifications

Effective Plotting Area	610 x 510 mm
Maximum Media Width	200.8″ (510 mm)
Maximum media thickness	T / TD: 1″ | RT / RC: .8″ (RC: 10 mm / T: 2 mm)
Maximum Cut Speed	166.5″ (423.0 mm)
Maximum Cut pressure (Metric grams)	Eccentric: 1000g | Tangential / Creasing: 1500g
Cutter Types	Pen/swivel, High-pressure Tangential, Reciprocating
Interface	USB2.0, RS-232C, Ethernet
Power supply	Single-phase (AC 100–120V / AC 220–240V), 145 VA or less
Power consumption	500 W or less
Operational Environment	Operational Temperature 41° – 95° F Operational Humidity: 35–75 % RH (Non condensing)
Dimensions (W × D × H)	51.97″ x 41.14″ x 43.30″ (132 x 104.5 x 110 cm)
Weight	240.3 lbs. (109 kg)
Certifications	VCCI class A, FCC class A, ETL UL 60950-1 | CE Marking (Machinery directive, RoHS), CB, REACH
